Understanding the Brother electronic knitting machine

The first step in reanimating my broken Brother KH-950i knitting machine with the Knitic system is understanding the principles of how Brother electronic knitting machines work. Fortunately the KH-910 and KH-940 service manuals (both downloadable from Knitting Machines etc.) are really useful in this regard.

The basic setup

The knitting machine electronics can be broken down into core modules which perform specific functions. These fortunately don’t appear to change much between models.

Disclaimer: I only have limited first hand experience of the 950i electronics. Details may not be accurate, especially for different models.

Knitting machine electronics diagram

Main PC Board

950i_Main_PCB
The 950i Main PCB

The brains of the operation, in charge of co-ordinating all of the other parts of the system and performing the necessary calculations of carriage position and direction etc.

Operation PC Board

The user interface controller. It accepts the user input in the form of key presses, and displays the output in the form of LEDs and numerical displays. It lies between the main PCB and the pattern case on the 950i. Also called the control PC board in later model service manuals.

Left and Right position sensor boards

950i_end_sensor_belt
The 950i left end sensor board

Located at the left and right ends of the needle bed behind the turn marks, these signal when a carriage has passed the turn mark and indicate its type (Knit, Lace or Garter).

Each carriage includes a sensor magnet which is detected by the hall effect sensor in the end position PCBs when the carriage moves past. The sensor responds differently to north and south magnetic poles, so the different carriage types use different magnet alignments in order to be distinguished between.

Knit carriage

k-carriage-end-sensor

The Knit (K) carriage sensor magnet has its north pole closest to the end sensor. When the carriage approaches the output voltage of the end sensor increases until it reaches its maximum when the magnet and sensor are aligned (the point of closest approach).

Lace carriage

L-carriage-end-sensorThe Lace (L) carriage sensor magnet has its south pole closest to the end sensor. When the carriage approaches the output voltage of the end sensor decreases until it reaches its minimum when the magnet and sensor are aligned (the point of closest approach).

Garter Carriage

g-carriage-end-sensorThe Garter (G) carriage has two sensor magnets with the north/south axis parallel to the direction of travel.

Whichever direction the carriage is travelling in, the sensor will detect a south pole followed by a north pole when the first magnet moves past. According to the KH-695 service manual the north pole must be detected within 3 needles of the south pole.

Encoder PC Board

950i_encoder
The two concentric 950i rotary encoders seen underneath the encoder PC board and behind the right end sensor board.

Comprised of an optical incremental rotary encoder. The carriage connects to the timing belt which turns the rotary encoder(s). The encoder provides the signals required for calculating the amount and direction of carriage movement.

Standard Gauge Machines

Standard gauge machines have 4.5mm needle spacing and 200 needles. There are 16 solenoids and 8 needle selector plates in the needle selection mechanism.

The rotary encoders have two rings of teeth. The outer ring has 48 teeth, each representing one needle, and two opto-interrupter sensors offset by the width of half a tooth (V1 and V2).

There is an additional inner ring with 3 teeth and one opto-interrupter sensor. This provides the belt phase (BP) signal.

encoder-signalsPseudo-code for calculating the carriage direction and position:

  • IF V2 is HIGH AND V1 rises from LOW to HIGH  THEN
    • carriage is travelling to the right
    • IF carriage is detected at left end sensor THEN
      • position counter is 1
      • determine carriage type (K, L or G)
      • check belt phase to determine solenoid number
    • ELSE increase position counter and solenoid number by 1
  • ELSE IF V2 is HIGH AND V1 falls from HIGH to LOW THEN
    • carriage is travelling to the left
    • IF carriage is detected at right end sensor THEN
      • position counter is 200
      • determine carriage type (K, L or G)
      • check belt phase to determine solenoid number
    • ELSE decrease position counter and solenoid number by 1
Belt Phase

The timing belt has a repeating series of circular holes interspersed with a horizontally elongated hole every 8 needles. The carriage engages with the belt at this elongated hole using connecting hook.

The needle selection mechanism operates with a 16 needle repeat. As the timing belt connector hole pitch is 8 needles there are two locations within each 16 needle repeat at which the connection could have been made and two possible solenoids to control the needle. The belt phase signal is used to decide which of the connection two locations was used and therefore which is the correct solenoid number.

The table below shows how the combination of carriage and belt phase signal translates to the solenoid number.

Belt Phase table

Bulky/Chunky gauge machines

The KH-270 chunky gauge machine has 9mm needle spacing and 112 needles. The needle selector mechanism has 12 solenoids and 6 needle selector plates.

The encoder behaves in the same way as the standard gauge machine but only has the outer ring of teeth and V1 and V2 signals as there is no need for the BP signal (I assume this means that the timing belt connector hole pitch is 12 needles). The solenoid to needle number mapping is available in the service manual.

Solenoid PC Board

Actions the solenoid selection signals provided by the main PC board by turning the solenoids on and off.

In the 950i this is buried somewhere under the card reader mechanism. I haven’t figured out how (nor been brave enough to try!) to disassemble the machine to get at the solenoid PC board yet.

Power Supply

The machines require two DC voltages to operate: 5V for the logic circuits and, depending on the model, 7.5V or 12V for the solenoids. Older models contain internal AC to DC converter and voltage regulation circuits, newer models have external adapters supplying the higher DC voltage and voltage regulators are used to generate the required 5V logic supply.

The 910 and 950i have internal AC to DC converting power supply boards which provide 5V (red cables) and 12V (orange cables).

Card reader (optional)

950i_card_reader
The 950i mylar card reader. On the left is the card feed stepper motor. The read head in the centre moves along the spiral axis driven by a DC motor.

The 910, 950i and perhaps one or two other models came with mylar pattern card readers. The card feed row and read head stitch position are controlled by stepper and DC motors respectively, and the read head signal indicates whether the corresponding pattern square is shaded in or left blank.

The Knitic system marks the card reader rather redundant so I haven’t included information about the card reader but it is available in the KH-910 service manual.

External memory devices (optional)

An interface for the optional PPD (pattern programming devices) and floppy disk external memory systems.

I have neither system and again they are made redundant with the Knitic system being able to transfer patterns directly from the computer via the substitute electronics.

Mapping the connectors and pins

Now that I have a better understanding of the various electronics modules, what they do and why they are needed the next job is to identify the connectors removed from the old main PC board and map the individual pins to their purposes.
